Taille de roues
|
29"
|
|---|
|
Fourche
|
Rock Shox Reba RL 29, PushLoc, 15QR Maxle, tapered
|
|---|
|
Débattement avant
|
120 mm
|
|---|
|
Amortisseur
|
Fox Float CTD BoostValve, 200x51mm, Climb/Trail/Descend mode, LV air canister
|
|---|
|
Débattement arrière
|
120 mm
|
|---|
|
Commandes
|
Shimano Deore XT SL-M780-I Rapidfire-Plus, direct attach
|
|---|
|
Pédalier
|
Shimano XT, FC-M782, 40x30x22T, 175mm (180mm for largest frame size)
|
|---|
|
Dérailleur avant
|
Shimano XT, FD-M781-A, direct mount, Down Swing, 3x10-speed
|
|---|
|
Dérailleur arrière
|
Shimano XT, RD-M781-SGSL, Shadow 10-speed
|
|---|
|
Freins
|
Shimano Deore XT K-M7851 hydr. Discbrake (180/180mm)
|
|---|
|
Moyeux
|
DT CSW AM 2.9 straightpull wheelset, 28/32 spokes, 15QR/X12, 622x23C rim, alloy nipples
|
|---|
|
Jantes
|
DT CSW AM 2.9 straightpull wheelset, 28/32 spokes, 15QR/X12, 622x23C rim, alloy nipples
|
|---|
|
Pneus
|
Schwalbe Nobby Nic Kevlar SnakeSkin 2.35
|
|---|
|
Potence
|
Syntace F149, 31.8mm, 6°
|
|---|
|
Cintre
|
CUBE Flat Race Bar Pro, 720mm, 9°
|
|---|
|
Tige de selle
|
Rock Shox Reverb Stealth 31.6mm, 125mm adjustable seatpost, internal routing
|
|---|
|
Selle
|
Selle Italia X1
|
|---|
|
Grips
|
CUBE Race Grip, 1-clamp
|
|---|
|
