Taille de roues
|
29"
|
|---|
|
Fourche
|
Manitou Marvel 29 Comp TS air w/ tapered alloy steerer, lockout
|
|---|
|
Débattement avant
|
100 mm
|
|---|
|
Commandes
|
Shimano Deore, M610 Rapid Fire
|
|---|
|
Chaîne
|
KMC X10
|
|---|
|
Pédalier
|
Shimano Deore, M615 hollow Tech II w/ integrated spindle, 38x24
|
|---|
|
Dérailleur avant
|
Shimano M616D, direct-mount
|
|---|
|
Dérailleur arrière
|
Shimano Deore XT, M781 SGS Shadow top normal
|
|---|
|
Cassette
|
Shimano Deore HG62, 11-36
|
|---|
|
Freins
|
Hayes Prime Sport, hydraulic disc, 180/160mm
|
|---|
|
Moyeux
|
Formula DC-71 sealed bearing front / DHT-142 rear, 32H disc hubs
|
|---|
|
Jantes
|
Sun Inferno 25 rims
|
|---|
|
Pneus
|
Schwable Rapid Rob 26" x 2.25"
|
|---|
|
Potence
|
Oval M313, 3D-forged alloy, 31.8mm clamp diameter, 6° rise
|
|---|
|
Cintre
|
Oval M250, alloy riser bar, 9° sweep, 31.8mm diameter, 710mm wide, +/- 5mm rise
|
|---|
|
Tige de selle
|
Oval M300, alloy double-bolt micro-adjust, 31.6mm x 350mm
|
|---|
|
Selle
|
Oval M200 w/ steel rails
|
|---|
|
Grips
|
Oval dual-density Kraton, lock-on
|
|---|
|
